Frame KIDS26, Alloy 6061, custom tubing, semi int. CBR, BB68, SCOTT dropout, PM
Fork SR Suntour XCE2880mm travel Softer spring setup
Rear Derailleur Shimano Tourney RD-M30208 Speed
Shifters Shimano SL-RV400-8RRevo Shifter
Crankset Prowheel, Alloy Crank 140mm32T, w/CG PVG single cover
BB-Set Feimin, BB68, cartridge, square taper
Chain KMC Z8.3
Cassette Shimano CS-HG400-811-40T, 8-Speed
Brake Levers Tektro HD-M276
Brakes Tektro HD-M276, Hydr. Disc160F/160R rotor, short reach lever
Handlebar LEADTEC Kids riser bar alloy D:19580mm, 20mm Rise Syncros Grips Kids 100/80
H'stem LEADTEC Alloy 50mm, +10°, 25.4 clamp
Seatpost Alloy, 31.6mm, 300mm
Seat Syncros Future Pro
Headset Feimin SCT Syncros HS OE Pressfit, ZS56-62mm
Hub (Front)Formula 5x100mm, 32H, disc 6 bolt
Hub (Rear)Formula 5x135mm, 32H, disc 6 bolt
Spokes15G, stainless, black
Rims Alloy anodized black, disc
Front Tire Kenda K1227 Booster, 26x2.2", 30TPI
Rear Tire Kenda K1227 Booster, 26x2.2", 30TPI
Pedals Feimin FP-803, w/Reflector
Approx weight in KG12.3
Approx weight in LBS27.12
Max. System Weight 70kgThe overall weight includes the bike, the rider, the equipment, and possible additional luggage.
